Elevator control panel / elevator control cabinet with speed ≤4m/s
110VDC Elevator Control Panels / Elevator Control System Cabinet 48F Max Floors
| | SN-MTCC-Y2/Y3/Y4 | SN-MTCC-W1/W2 |
| Speed | ≤4m/s |
| Max.floors | 48F |
| Integrated controller | MONT70 |
| The man-machine exchange signal acquisition party | Complete series, series and parallel |
| Standard adaptive power supply | Three phases 380VAC,Three phases 220VAC |
| Brake voltage | 110VDC |
| Remote operating voltage | No | 220VAC |
| Adaptive elevator type | Machine room | No machine room |
| Adaptive motor | Permanent magnet synchronous traction machine, AC asynchronous motor |
| Brake resistor | Build-in | External |
| Mounting mode | Floor type,wall mounting type | Floor type |
| Selectable function | Advanced open function UCMP function Brake strong excitation function(select brake strong excitation contactor and holding resistor) Group control function Intellectual voice intercom |
| Size | Production size(mm) | Mounting size for floor type(mm) | Mounting size for wall-mounting type(mm) |
| | W | H | D | L | W1 | d1 | W2 | H2 | d2 |
| SN-MTCC-Y2 | 600 | 1000 | 300 | 560 | 200 | 12 | 550 | 1050 | 12 |
| SN-MTCC-Y3 | 680 | 1250 | 300 | 640 | 200 | 12 | 630 | 1300 | 12 |
| SN-MTCC-Y4 | - | - | - | - | - | - | - | - | - |
| SN-MTCC-W1 | 400 | 1700 | 240 | 350 | 160 | 12 | - | - | - |
| SN-MTCC-W2 | 435 | 1670 | 220 | 385 | 135 | 10 | - | - | - |
Production and installation size
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
