FUJI Stainless Steel Freight Car Cargo Passenger Elevator with Roomless Machine
FUJI Elevator series MRL freight elevator, using the advanced permanent magnet synchronous gearless traction technology, reasonable design, without room; the traction machine has the advantage of light weight, small volume saving the architectural space, greatly improve the performance and quality of machine roomless elevator, reduce energy consumption, the failure rate.
FUJI Elevator series MRL freight elevator with less shaft height, reduce the design height of the factories and other buildings, can meet the actual needs of the enterprise. To be the best choice for the transportation of goods, such as factories, warehouses, department stores, property centers, libraries and so on.
●Space saving
●Energy saving advantage
●Quiet operation
Machine Roomless (MRL) Freight Elevator Specifications
| Load (kg) | Speed (m/s) | Exterior size of car(mm) WxDxH | Net door opening(mm) WxH | Door Open Type | Shaft size(mm) |
| WxD | OH | PIT |
| 1000 | 0.5 | 1500x1800x2200 | 1200x2100 | Two panel side opening | 2250x2200 | 4500 | 1500 |
| 1.0 | 4500 | 1500 |
| 1.5 | 4600 | 1600 |
| 2.0 | 4800 | 1800 |
| 2000 | 0.5 | 2000x2300x2200 | 1500x2100 | Two panel side opening | 3150x2660 | 4800 | 1500 |
| 1.0 | 5000 | 1500 |
| 1.5 | 5200 | 1600 |
| 2.0 | 5200 | 1800 |
| 3000 | 0.5 | 2470x2560x2200 | 1800x2100 | Four panel center opening | 3700x3000 | 5000 | 1600 |
| 5000 | 0.5 | 2800x3400x2500 | 2400x2400 | Four panel center opening | 4250x3800 | 6100 | 1600 |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
